WX112(050) Singleturn Wire Wound Potentiometer

(3 customer reviews)

$9.99

5 W rated power single turn wirewound potentiometer. Application: adjust timer, speed, temperature.

1 kOhm10 kOhm100 Ohm2.2 kOhm22 kOhm220 Ohm33 kOhm4.7 kOhm47 kOhm
Clear

Description

The winding of a metal wire is used to make a resistor. It can withstand higher power than carbon or porcelain gold film. The potentiometer can be used as a voltage divider, a restat and a current controller. Good contact between the central sliding end and the resistor housing, smooth rotation. The housing of the potentiometer resistor has two fixed ends. By manually adjusting the rotating shaft or slider and changing the position of the movable contact on the resistor housing, the resistance value between the movable contact and any fixed end changes, thus changing the size of the voltage and current. High resolution, the resolution of the potentiometer reaches 100%.





Specifications
Type
Single Turn
Rated Power
5 W
Resistance
100 Ω ~ 47 kΩ
Resistance Tolerance
±5%
Technology
Wire Wound
Terminals
3 Pins
Body Size (D x H)
40 x 25 mm / 1.6″ x 1″
Screw Thread Diameter
10 mm / 0.4″
Shaft Diameter
6 mm / 0.24″
Shaft Length
9 mm / 0.35″
Total Length
45 mm / 1.8″



Additional information

Weight N/A

3 reviews for WX112(050) Singleturn Wire Wound Potentiometer

  1. S***e

    As advertised.

  2. P***z

    OK

  3. A***o

    Exactly as I expected, professionally built potentiometer.
