Electric Soldering Iron JCD 908S

(3 customer reviews)

$10.00$14.00

If you like DIY or need to repair small parts, JC D908S soldering iron will do the job for you and is your best choice.

110 V220 V
JCD-908SAJCD-908SBJCD-908SCJCD-908SDJCD-908SEJCD-908SFJCD-908SG
EUUS
Clear
SKU: 1005001634455831 Category: Tags: , , , ,

Description

JCD 908S

Electric Soldering Iron

Security is heating up fast
PA66 anti-skid upgrade
Reinforced iron core



JCD 908S Soldering Iron is Suitable for Beginners Convenience to Use

If you like DIY or need to repair small parts, JC D908S soldering iron will do the job for you and is your best choice.



A Soldering Iron is a Hand Tool Used in Soldering

It supplies heat to melt solder so that it can flow into the joint between two work pieces. More advanced irons for use in electronics have a mechanism with a temperature sensor and method of temperature control to keep the tip temperature steady.





Instructions:

  • Press the (+) button once to increase 1 °C, press and hold it to increase temperature continuously.
  • Press the (-) button once to reduce 1 °C, press and hold it to reduce temperature continuously.
  • The newly set temperature will be saved after 3 seconds, and will keep the temperature for next time powering-on. When (F) or (C) symbol flashes, it means the heating core has not reached the set temperature.



Soldering Iron Advantages

Electroplating Process

Intelligent Temperature Control

Liquid

Crystal Display

Rapid

Heating

Excellent Workmanship



Internal Heat Iron

Soldering iron comes with LCD display soldering iron. pcs heating wires built inside solder gun, temperature control and adjusts with PID (proportional-integral-derivative) technology.

The Iron Solder Use an Inner-Heated Ceramic Core With 80 W Whith Heat Up to Operating Temperatures in 15 – 20 seconds

Heat-resistant screw head can insulate temperature effectively to get a long cool handle.



Parameter Setting:

1. To press the red and white button both at the same time before it is power on, power on,after the LCD is working, stop to press the button, you will enter the setting menu. The LCD shows (F) or (C)

2. Press the white button to choose C(degree centigrade) or F (Fahrenheit). Press the Red button to choose Element U10 (01), U20 (02), U30 (03), U40 (04).

3. Pressing the (- ) and (+) at the same time to save your setting operation and quit the setting menu (finished) To protect the user from scald, when on the setting menu, it will stop heating. Failure warning indication The LCD shows (OP): the heating element is open circuit.

Solution:

  • Change the element.
  • To confirm that whether the pin of element is oxidized. The LCD shows(E1) The outlet is poor contact, or the battery source interfering the soldering iron that it is power down.

Solution:

  • Unplug the soldering iron.
  • Close the interfering source.
  • To use it far away from the interfering source.



Specifications

Voltage AC 220 – 240 V,  AC 100 – 130 V
Power 80 W
Frequency 50 – 60 Hz
Temperature Range 180 – 500 ℃
Temperature Stability ± 5 ℃
Heating Type Wmore Ceramics Element
Wire Length 1.4 meter
Soldering Iron Size 242 x 25 x 25 mm

Additional information

Weight 0.2 kg
